4. Router Parameters Setting

Conguring computer network card IP address:

Congure your network card’s TCP/IP properties to Obtain

an IP address automatically from router, or set the

computer’s IP with the same network mask of the router.

(For example: Router’s default IP is 192.168.1.1 /

255.255.255.0)

Thenyoucansetcomputer’sIPto:

192.168.1.x / 255.255.255.0

(Therangeforxisfrom2to254)

Web setting interface:

Open IE or Netscape Web browser, Input

http://192.168.1.1 (Router default IP address) in the

address column, then click <ENTER> button, access the

followingsettinginterface:

Input user name and password, then click Login key to

enterWEBsettinginterface.

Default setting:

IP Address: 192.168.1.1

Subnet Mask: 255.255.255.0

Username / Password: admin / admin

After type right username and password, the following

windowwillpopup:

Figure 3: The main setup screen

5. Further Conguration

The above steps introduce simple installations and

congurations for ADE-3400 / ADE-4400. For further

congurations of WAN, LAN, NAT, Security, Routing, DNS,

andDSLetc,pleaserefertotheuser’smanualintheCD.If

you have other questions, please contact the local dealer

ordistributorwhereyoupurchasedthisproduct.
