IDL series User Guide
130
Output:
Verbose Mode On
Entry Created
ifname : abond-0 lowif : dsl-0
AsmRxGroupIntf : abond-0 AsmRxLinkIndex : dsl-0
TxLinkAdminStatus : enable RxLinkAdminStatus : enable
TxLinkOperStatus : Disable RxLinkOperStatus : Disable
AsmTxLinkStatus : SelectedToCarryBondingTraffic
AsmRxLinkStatus : SelectedToCarryBondingTraffic
Verbose Mode Off:
Entry Created
Output Fields:
Field Description
ifname
This specifies the interface index used for the ATM Based Multi pair
Bonding type of interfaces. Valid Value is abond-X. Link can not be
created , deleted or modified if associated abond group interface is
enabled.
lowif
This specifies the interface index used for the abond link (DSL) entry.
Valid Value is dsl-X ,dsli-X , dslf-X
AsmRxGroupIntf
Abond group Interface Index of proxy link.
AsmRxLinkIndex
Lower Interface Index of Proxy link.
TxLinkAdminStatus
This specifies the Tx Status for the link in a Group.
RxLinkAdminStatus
This specifies the Rx Status for the link in a Group.
TxLinkOperStatus
The current operational status of the abond link in Tx direction.
RxLinkOperStatus
This specifies the rx operational Status for the link in a Group.
AsmTxLinkStatus
The current Tx Link status of the abond link as reflected in ASM
Messages.
AsmRxLinkStatus
The current Rx Link status of the abond link as reflected in ASM
Messages.
