IP DSLAM
241
5.9.5 ADSL ATUC Chanlntvl Commands
5.9.5.1 Get adsl atuc chanintvl
Description:
Use this command to get.
Command Syntax:
get adsl atuc chanintvl [ifname <interface-name>] [nintrvl <nintrvl-val>]
Parameters:
Name Description
ifname <fname-val>
The ADSL ATUC channel interface name.
Type: Get － Mandatory
Valid values: dsli-0 – dsli-23
nintrvl <nintrvl-val>
Performance Data Interval number.
Type: Get － Mandatory
Valid values: 1 - 96
Example:
$ get adsl atuc chanintvl ifname dsli-0 nintrvl 1
Output:
Ifname : dsli-0 IntervalNumber : 1
Rx Blocks : 10 Tx Blocks : 45
Corrected Blocks : 20 Uncorrected Blocks : 1
Gs Time Elapsed(sec) : 30 Valid Data : true
GsNoCellDelineation : 20 GsHeaderErrorCheck : 0
GsOutOfCellDelineation : 0 AtucChanIntvlNcds : 20
AtucChanIntvlLcds : 20
Output Fields:
FIELD Description
Ifname
The ADSL ATUC channel interface name.
IntervalNumber
Performance Data Interval number.
Rx Blocks
Count of all encoded blocks received on this channel during this interval.
Tx Blocks
Count of all encoded blocks transmitted on this channel during this
interval.
Corrected Blocks
Count of all encoded blocks received with errors that were corrected on
this channel during this interval.
