IDL series User Guide
146
5.4.5 LACP AGGRPort List Commands
5.4.5.1 Get lacp aggrport list
Description:
Use this command to get a LACP aggregator port list.
Command Syntax:
get lacp aggrport list [aggrifname <aggrifname-val>]
Parameters:
Name Description
Aggrifname
<aggrifname-val>
The Aggregator interface name.
Type : Optional
Valid values: aggr-*
Mode:
Super-User, User
Example:
$ get lacp aggrport list
Output:
Aggr IfName : aggr-0
Port List : eth-0 eth-1
Output Fields:
Field Description
Aggr IfName
The Aggregator interface name.
Port List
List of the ports corresponding to given aggregator index.
References:
z lacp aggr
z lacp aggrport info
z lacp aggrport stats.
