16 17
SUZLON Energy Ltd.
Pune, India
4
PROJECT OUTLINE
Others
AC unit
Split System × 4
SkyAir × 3
Control System
intelligent Manager
Ⅲ
× 4
Interface for use in BACnet
®
× 1
RWEYQ30MY1 × 17
RWEYQ20MY1 × 33
RWEYQ10MY1 × 4
RXYMQ5PVE × 1
RXYQ5PAY6 × 3
RXYQ8PAY6 × 5
RXYQ12PAY6 × 1
RXYQ16PAY6 × 5
RXYQ18PAY6 × 2
RXYQ36PAY6 × 1
FXFQ32PVE × 28
FXFQ40PVE × 9
FXFQ50PVE × 55
FXFQ63PVE × 67
FXFQ80PVE × 78
FXFQ100PVE × 52
FXFQ125PVE × 29
FXMQ100PVE × 23
FXMQ80PVE × 3
FXMQ125PVE × 7
FXMQ200MAVE × 8
FXMQ250MAVE × 7
FXDQ20PBVE × 85
FXDQ25PBVE × 63
FXDQ32PBVE × 45
FXDQ40NBVE × 47
FXDQ50NBVE × 40
FXDQ63NBVE × 12
FXAQ25MAVE × 3
FXAQ32MAVE × 8
FXAQ40MAVE × 2
FXAQ50MAVE × 1
FXAQ63MAVE × 30
Outdoor unit Indoor unit
EQUIPMENT
Pune, India
Office
4F
2009
24,980m
2
Location
Application
Number of floors
Project year
Total floor area
OFFICE
