Ports required for this popular application in the location (1-10)

you’d specified.

Add Special Application Fill in the "Trigger Port", "Trigger Type”, “Public Port”, "Public

Type", "Public Port" and "Comment" of the setting to be added

and then click "Add". Then this Special Application setting will be

added into the "Current Trigger-Port Table" below. If you find any

typo before adding it and want to retype again, just click "Clear"

and the fields will be cleared.

If you want to add a popular application, select one “Popular

Application” and then click “Add”.

Remove Special Application If you want to remove some Special Application settings from the

"Current Trigger-Port Table", select the Special Application

settings you want to remove in the table and then click "Delete

Selected". If you want remove all Special Application settings

from the table, just click "Delete All" button. Click "Reset" will

clear your current selections.

Click <Apply> at the bottom of the screen to save the above configurations. You can now

configure other advance sections or start using the router (with the advance settings in place)

Example: Special Applications

If you need to run applications that require multiple connections, then specify the port (outbound)

normally associated with that application in the "Trigger Port" field. Then select the protocol type

(TCP or UDP) and enter the public ports associated with the trigger port to open them up for

inbound traffic.

Example:

Trigger Port Trigger Type Public Port Public Type Comment

1 28800 UDP 2300-2400, 47624 TCP MSN Game Zone

2 6112 UDP 6112 UDP Battle.net

In the example above, when a user trigger’s port 28800 (outbound) for MSN Game Zone then the

router will allow incoming packets for ports 2300-2400 and 47624 to be directed to that user.

Note: Only one LAN client can use a particular special application at a time.

2.6.4 UPnP Settings

With UPnP, all PCs in you Intranet will discover this router automatically. So you do not have to

do any configuration for your PC and can access the Internet through this router easily.
