Hardware Installation

1. Unpack the FPS-1010M / FPS-1010MG package and verify the items listed in the

previous section are provided.

2. Use USB cable to connect FPS-1010M / FPS-1010MG to the MFP or printer that

you want to share to your network.

3. Use a RJ-45 cable to connect the FPS-1010M / FPS-1010MG to your LAN.

4. Connect dipole antenna to FPS-1010MG antenna connector. (FPS-1010MG only)

5. Connect the bundled power adapter to FPS-1010M / FPS-1010MG. The MFP

Server will perform the Power-On-Self-Test (POST) after power on. Please wait

for 20 seconds.

Note

1. Please use the power adapter which bundled with MFP Server.

DO NOT use any other power adapter from other sources. That

may cause your FPS-1010M / FPS-1010MG damage.

2. To prevent the compatibility problem between FPS-1010M /

FPS-1010MG and a few MFP or printer, it is recommended that

you power on the FPS-1010M / FPS-1010MG before the MFP or

printer.
