7. Start Web Management

The following shows how to start up the Web Management of the Managed

Industrial Switch. Note the Managed Industrial Switch is congured through an

Ethernet connection, please make sure the manager PC must be set on the same

IP subnet address.

For example, the default IP address of the Managed Industrial Switch is

192.168.0.100, then the manager PC should be set at 192.168.0.x (where x

is a number between 1 and 254, except 100), and the default subnet mask is

255.255.255.0.

PC / Workstation

with

IE Browser

ISW Managed Industrial Switch

IP Address:

192.168.0.x

RJ-45 / UTP Cable

IP Address:

192.168.0.100

Figure 7-1 IP Management Diagram

1. Use Internet Explorer 6.0 or above Web browser, enter IP address

http://192.168.0.100 (the factory-default IP address or that you have just

changed in console) to access the Web interface.

2. When the following dialog box appears, please enter the default user name

“admin” and password “admin” (or the username/password you have changed

via console). The login screen in Figure 7-2 appears.

Default User name: admin

Default Password: admin
