English 4
[Drainage through Drainpipe]
• Make sure that the drainpipe is installed prop-
erly to drain water.
If no water is discharged from the drainpipe while
the air conditioner is cooling operation, the drain-
pipe may be clogged with dust or dirt and water
leakage from the indoor units may result.
Stop operating the air conditioner and consult
your dealer.
2. SPECIFICATIONS
[RXYQ]
[REYQ]
Model name
RXYQ72PYDN RXYQ96PYDN RXYQ120PYDN
Power supply
Phase
—3~3~3~
Frequency
(Hz) 60 60 60
Voltage
(V) 460 460 460
Nominal cooling capacity
(MBh) 72 96 120
Nominal heating capacity
(MBh) 81 108 135
66-1/8× 66-1/8× 66-1/8×
Dimensions H×W×D
(inch) 36-5/8×30-1/8 36-5/8×30-1/8 36-5/8×30-1/8
Mass
(Ib) 573 573 573
Refrigerant
type
— R410A R410A R410A
charge (*1)
(Ib) 18.1 19.8 20.1
Design pressure
High side
(psig) 478 478 478
Low side
(psig) 320 320 320
Model name
RXYQ144PYDN RXYQ168PYDN RXYQ192PYDN
Power supply
Phase
—3~3~3~
Frequency
(Hz) 60 60 60
Voltage
(V) 460 460 460
Nominal cooling capacity
(MBh) 144 168 192
Nominal heating capacity
(MBh) 162 189 216
(66-1/8×36-5/
8×30-1/8)+
(66-1/8×36-5/
8×30-1/8)+
(66-1/8×36-5/
8×30-1/8)+
Dimensions H×W×D
(inch)
(66-1/8×36-5/
8×30-1/8)
(66-1/8×36-5/
8×30-1/8)
(66-1/8×36-5/
8×30-1/8)
Mass
(Ib) 573+573 573+573 573+573
Refrigerant
type
— R410A R410A R410A
charge (*1)
(Ib) 18.1+18.1 18.1+19.8 18.1+20.1
Design pressure
High side
(psig) 478 478 478
Low side
(psig) 320 320 320
Model name
RXYQ216PYDN RXYQ240PYDN
Power supply
Phase
—3~ 3~
Frequency
(Hz) 60 60
Voltage
(V) 460 460
Nominal cooling capacity
(MBh) 216 240
Nominal heating capacity
(MBh) 243 270
(66-1/8×36-5/
8×30-1/8)+
(66-1/8×36-5/
8×30-1/8)+
Dimensions H×W×D
(inch)
(66-1/8×36-5/
8×30-1/8)
(66-1/8×36-5/
8×30-1/8)
Mass
(Ib) 573+573 573+573
Refrigerant
type
— R410A R410A
charge (*1)
(Ib) 19.8+20.1 20.1+20.1
Design pressure
High side
(psig) 478 478
Low side
(psig) 320 320
Model name
RXYQ72PTJU RXYQ96PTJU RXYQ120PTJU
Power supply
Phase
—3~ 3~ 3~
Frequency
(Hz) 60 60 60
Voltage
(V) 208-230 208-230 208-230
Nominal cooling capacity
(MBh) 72 96 120
Nominal heating capacity
(MBh) 81 108 135
Dimensions H×W×D
(inch)
66-1/8×36-5/8×
30-1/8
66-1/8×36-5/8×
30-1/8
66-1/8×36-5/8×
30-1/8
Mass
(Ib) 560 560 560
Refrigerant
type
— R410A R410A R410A
charge (*1)
(Ib) 18.1 19.8 20.1
Design pressure
High side
(psig) 478 478 478
Low side
(psig) 320 320 320
Model name
RXYQ144PTJU RXYQ168PTJU RXYQ192PTJU
Power supply
Phase
—3~ 3~ 3~
Frequency
(Hz) 60 60 60
Voltage
(V) 208-230 208-230 208-230
Nominal cooling capacity
(MBh) 144 168 192
Nominal heating capacity
(MBh) 162 189 216
Dimensions H×W×D
(inch)
66-1/8×
51-3/16×
30-1/8
(66-1/8×36-5/8×
30-1/8)+
(66-1/8×36-5/8×
30-1/8)
(66-1/8×36-5/8×
30-1/8)+
(66-1/8×36-5/8×
30-1/8)
Mass
(Ib) 747 560+560 560+560
Refrigerant
type
— R410A R410A R410A
charge (*1)
(Ib) 24.5 18.1+19.8 18.1+20.1
Design pressure
High side
(psig) 478 478 478
Low side
(psig) 320 320 320
Model name
RXYQ216PTJU RXYQ240PTJU
Power supply
Phase
—3~ 3~
Frequency
(Hz) 60 60
Voltage
(V) 208-230 208-230
Nominal cooling capacity
(MBh) 216 240
Nominal heating capacity
(MBh) 243 270
Dimensions H×W×D
(inch)
(66-1/8×36-5/8×
30-1/8)+
(66-1/8×36-5/8×
30-1/8)
(66-1/8×36-5/8×
30-1/8)+
(66-1/8×36-5/8×
30-1/8)
Mass
(Ib) 560+560 560+560
Refrigerant
type
— R410A R410A
charge (*1)
(Ib) 19.8+20.1 20.1+20.1
Design pressure
High side
(psig) 478 478
Low side
(psig) 320 320
Model name
REYQ72PYDN REYQ96PYDN REYQ120PYDN
Power supply
Phase
—3~ 3~ 3~
Frequency
(Hz) 60 60 60
Voltage
(V) 460 460 460
Nominal cooling capacity
(MBh) 72 96 120
Nominal heating capacity
(MBh) 81 108 135
66-1/8× 66-1/8× 66-1/8×
Dimensions H×W×D
(inch) 51-1/4×30-1/8 51-1/4×30-1/8 51-1/4×30-1/8
Mass
(Ib) 732 732 732
Refrigerant
type
— R410A R410A R410A
charge (*1)
(Ib) 22.7 23.4 23.8
Design pressure
High side
(psig) 478 478 478
Low side
(psig) 320 320 320
01_EN_3P215731-1D.fm Page 4 Tuesday, February 5, 2008 6:35 PM
