Item Description

PPTP Server Specify the PPTP server IP address.

Password

Specify the corresponding password to login to the PPTP

server.

Conrm Password Retype the password.

Static IP Address Specify whether you have a static WAN IP address.

IP address Specify whether you have a static IP address.

Subnet Mask

Address

Specify your static WAN IP address if you have enabled

the “Static IP Address”.

DNS Server

Address

Specify the subnet mask address if you have enabled the

“Static IP Address”.

MAC Address Show MAC address information

Step 4: Setting the Wireless Network

This page allows the administrator to quickly setup the wireless Access Point (AP).

Specify the wireless conguration and then click the button “Next” to go to step 5.

Item Description

Access Point (AP) Enable or disable the wireless AP service.

Hide SSID

Decide whether or not to make the wireless AP SSID

visible.

Network Name

(SSID)

Specify the preferred SSID name string.

Wireless Region Select the area of location yours.

Wireless Mode

Select the preferred wireless AP mode:

802.11b / 802.11g / 802.11n.

Channel Select the preferred wireless channel number.

Authentication

Type

Specify the authentication type:

Open system / Shared Key / WPA / WPA2.

Data Encryption Select the Data Encrypt type.

Encrypt Strength Select the encrypt strength.

Security Key Specify the key for the clients to access this AP.
