![Daikin REYQ240PYDN [14/20] Optimum operation](/views2/1717999/page14/bge.png)
11 English
How to designate the master remote controller
(Refer to figure 10)
Press the operation mode selector button of the
current master remote controller for 4 seconds.
The display showing “ ” (changeover
under control) of all remote controllers con-
nected to the same outside unit flashes.
Press the operation mode selector button of
the controller that you wish to designate as the
master remote controller. Then designation is
completed. This remote controller is desig-
nated as the master remote controller and the
display showing “ ” (changeover
under control) vanishes.
The displays of other remote controllers show
“ ” (changeover under control).
How to change the operation mode
(Refer to figure 10)
Press the operation mode selection button of
the master remote controller, which does not
show “ ” (changeover under control)
repeatedly until the air conditioner is set to the
desired operation mode.
The display will change to FAN, DRY, AUTO
(REYQ models only), COOLING, or HEATING
each time the button is pressed.
The other remote controllers with no option
rights will follow suit and change their displays
automatically.
6-6 PRECAUTIONS FOR GROUP CON-
TROL SYSTEM OR TWO REMOTE
CONTROLLER CONTROL SYSTEM
This system provides two other control systems
beside individual control (one remote controller con-
trols one indoor unit) system. Confirm which type of
your unit is the following system.
• Group control system
One remote controller controls up to 16 indoor
units. All indoor units are equally set.
• Two remote controller control system
Two remote controllers control one indoor unit (in
case of group control system, one group of indoor
units). The unit is individually operated.
NOTE
• Contact your Daikin dealer in case of chang-
ing the combination or setting of group control
and two remote controller control systems.
7. OPTIMUM OPERATION
Observe the following precautions to ensure the
system operates properly.
• Prevent direct sunlight from entering a room dur-
ing cooling operation by using curtains or blinds.
• Do not leave doors and windows open. If the
doors and windows remain open, air will flow out
of your room causing a decrease in the cooling or
heating effect.
• Do not use other heating devices directly beneath
the indoor unit.
If you do, they might get deformed by the heat.
• Never place objects near the air inlet or the air
outlet of the unit. It may cause deterioration in the
effect or stop the operation.
• Adjust the room temperature properly for a com-
fortable environment. Avoid excessive heating or
cooling.
• Ventilate often.
Extended use requires special attention to venti-
lation.
• When the display shows
“”
(time to clean the
air filter), ask a qualified service person to clean
the filters. (Refer to the chapter “Maintenance” in
the indoor unit manual.)
• Keep the indoor unit and remote controller at least
3.5ft. away from televisions, radios, stereos, and
other similar equipment.
Failing to do so may cause static or distorted pic-
tures.
• Turn off the main power supply switch to the unit
when the unit is not used for longer periods of
time. If the switch is on, it uses electricity. Before
restarting the unit, turn on the main power supply
switch 6 hours before operation to ensure smooth
running. (Refer to the chapter “Maintenance” in
the indoor unit manual.)
• Fully use the function of air flow direction adjust.
Cold air gathers on the floor, and warm air gathers
in the ceiling.
Set the air flow direction parallel during cooling or
dry operation, and set it downwards during heat-
ing operation.
Do not let the air blow directly to a person.
• It takes time for the room temperature to reach the
set temperature.
We recommend starting the operation in advance
using timer operation.
1
2
3
