Daikin REYQ240PYDN [17/20] Trouble shooting
![Daikin REYQ240PYDN [17/20] Trouble shooting](/views2/1717999/page17/bg11.png)
English 14
9-12 THE DISPLAY SHOWS
“”
• This is the case immediately after the main
power supply switch is turned on and means
that the remote controller is in normal condi-
tion. This continues for 1 minute.
9-13 THE COMPRESSOR OR FAN IN THE
OUTSIDE UNIT DOES NOT STOP
• This is to prevent oil and refrigerant from
remaining in the compressor. The unit will
stop after 5 to 10 minutes.
9-14 THE INSIDE OF OUTSIDE UNIT IS
WARM EVEN WHEN THE UNIT HAS
STOPPED
• This is because the crankcase heater is warm-
ing the compressor so that the compressor
can start smoothly.
9-15 HOT AIR IS EMITTED EVEN THOUGH
THE UNIT IS STOPPED
• Hot air can be felt when the unit is stopped.
Several different indoor units are being run on the
same system, so if another unit is running, some
refrigerant will still flow through the unit.
9-16 DOES NOT COOL VERY WELL
• Program dry operation.
Program dry operation is designed to lower the
room temperature as little as possible.
Refer to page 8.
10. TROUBLE SHOOTING
If one of the following malfunctions occur, take
the measures shown below and contact your
Daikin dealer.
WARNING
Stop operation and shut off the power if any-
thing unusual occurs (burning smells, etc.)
Leaving the unit running under such circumstances
may cause breakage, electrical shock, or fire.
Contact your dealer.
• If a safety device such as a fuse, a breaker or an
earth leakage breaker frequently actuates;
Measure : Do not turn on the main power switch.
• If the ON/OFF switch does not properly work;
Measure: Turn off the main power switch.
• If water leaks from unit;
Measure: Stop the operation.
• The operation mode selector button does not
work well.
Turn off the power.
• If the display “ ”, the unit number and the
operation lamp flash and the malfunction code
appears; (Refer to figure 12)
1. Inspection display
2.
Indoor unit number in which a malfunction occurs
3. Operation lamp
4. Malfunction code
Measure: Notify your Daikin dealer and report the
malfunction code.
If the system does not properly operate except for
the above mentioned cases and none of the above
mentioned malfunctions is evident, investigate the
system according to the following procedures.
If it is impossible to fix the problem after checking
all the above items, contact your dealer.
Let him know the symptoms, system name, and
model name.
1. If the system does not operate at all;
• Check if there is no power failure.
Wait until power is restored. If power failure occurs
during operation, the system automatically restarts
immediately after the power supply is recovered.
• Check if no fuse has blown;
Turn off the power supply.
• Check if the breaker is
blown.
Turn the power on with
the breaker switch in the
off position.
Do not turn the power on
with the breaker switch in
the trip position.
(Contact your dealer.)
2. If the system stops soon after starting the operation;
• Check if air inlet or outlet of outside or indoor unit
is not blocked by obstacles.
Remove any obstacle and make it well-ventilated.
• Check if the remote controller display shows
“”
(time to clean the air filter);
Refer to the operation manual of the indoor unit.
And clean the air filter.
3. The system operates but cooling or heating is
insufficient;
• Check if air inlet or outlet of outside or indoor unit
is not blocked by obstacles.
Remove any obstacle and make it well-ventilated.
TEST
Switch
ON
OFF
Trip position
Breaker
01_EN_3P215731-1D.fm Page 14 Tuesday, February 5, 2008 6:35 PM
