VAM350~2000FB
Total Heat Exchanger
HRV (Heat Reclaim Ventilation)
4P333249-1A – 2012.11
Installation manual
9
VAM800F, VAM1000F VAM1500F, VAM2000F
1
3
8
12
11
10
10
10
2
2
8
1
7
12
15
14
1
16
13
13
5
X35A
X24A
X33A
X14A
1 Electric component box
2 Printed circuit board
3 Electrical compartment cover
4 Securing screw and washer
5 Grounding terminal
6 Terminal board
7 Transmission wiring terminal board (P1, P2)
8 Transmission wiring (to optional remote controller)
9 Power supply cable
10
Wires for connection of additional external damper (supplied
accessory)
11
Insulated splices-closed barrel connector (0.75 mm
2
) (field
supply)
12
Double or reinforced insulated flexible cable (0.75 mm
2
) to
external damper (field supply)
13 Tie wrap (field supply)
14 BRP4A50A (optional accessory)
15 KRP2A51/61 (optional accessory)
16 CO
2
sensor (optional accessory)
