![Daikin VAM500FB [26/28] Wiring diagram](/views2/1719004/page26/bg1a.png)
Installation manual
22
VAM350~2000FB
Total Heat Exchanger
HRV (Heat Reclaim Ventilation)
4P333249-1A – 2012.11
Wiring diagram
The wiring diagram can be found on the service cover.
A1P .............................. PRINTED CIRCUIT BOARD
A2P~A4P ..................... PRINTED CIRCUIT BOARD ASSY (FAN)
A5P .............................. PRINTED CIRCUIT BOARD ASSY (FAN)
C1................................. CAPACITATOR (M1F)
F1U .............................. FUSE T, 5A, 250V (A1P)
F3U .............................. FUSE T, 6.3A, 250V (A2P, A3P, A4P, A5P)
HAP
...............................PILOT LAMP (SERVICE MONITOR-GREEN)
K1R .............................. MAGNETIC RELAY
K2R, K5R ..................... MAGNETIC RELAY
L1R∼L4R ...................... REACTOR
M1D, M2D .................... MOTOR (DAMPER)
PS ................................ SWITCHING POWER SUPPLY
Q1DI, Q2DI .................. FIELD EARTH LEAK DETECTOR
(MAX. 300mA)
R1T .............................. THERMISTOR (INDOOR AIR)
R2T .............................. THERMISTOR (OUTDOOR AIR)
R3T .............................. THERMISTOR (PTC)
S1C, S2C ..................... LIMIT SWITCH DAMPER MOTOR
X1M.............................. TERMINAL (A1P)
X2M.............................. TERMINAL (OUTSIDE INPUT) (A1P)
X3M.............................. TERMINAL (POWER SUPPLY)
V1R .............................. DIODE
Z1F............................... NOISE FILTER
REMOTE CONTROLLER
SS1 .............................. SELECTOR SWITCH
OPTIONAL ACCESSORIES
TES10 .......................... ADAPTER PC BOARD
CONNECTOR FOR OPTION
X14A ............................ CONNECTOR (CO2 SENSOR)
X24A ............................ CONNECTOR (OUTSIDE DAMPER)
X26A ............................ CONNECTOR (FILTER SIGN)
X33A ............................ CONNECTOR (ADAPTER PCB)
X35A ............................ CONNECTOR (POWER SUPPLY)
X41A ............................ CONNECTOR (HUMIDITY SENSOR 1)
X42A ............................ CONNECTOR (HUMIDITY SENSOR 2)
For VAM350-650
M1F .............................. MOTOR (SUPPLY AIR FAN)
M2F .............................. MOTOR (EXHAUST AIR FAN)
For VAM800-2000
M1F .............................. MOTOR (EXHAUST AIR FAN) (BOTTOM)
M2F .............................. MOTOR (SUPPLY AIR FAN) (BOTTOM)
M3F .............................. MOTOR (EXHAUST AIR FAN) (TOP)
M4F .............................. MOTOR (SUPPLY AIR FAN) (TOP)
: TERMINALS BLK : Black ORG : Orange
: CONNECTORS BLU : Blue RED : Red
: FIELD WIRING BRN : Brown WHT : White
: PROTECTIVE EARTH GRN : Green YLW : Yellow
: NOISELESS EARTH
