Daikin VAM350J7VEB [6/35] Specifications
![Daikin VAM350J7VEB [6/35] Specifications](/views2/1719225/page6/bg6.png)
• Indoor Unit • VAM-J
2
• Ventilation • VAM-J
4
2 Specifications
Notes
(1) Measured according to JIS B 8628 - 2003
(2) In accordance with commission regulation (EU) No 1253/2014
(3) Measured according to EN308 : 1997
(4) Clean the filter when the filter icon appears on the controller screen. Regular filter cleaning is important for delivered air quality and for the unit's energy efficiency.
(5) In accordance with regulation (EU) No 327/2011
Voltage range: units are suitable for use on electrical systems where voltage supplied to unit terminal is not below or above listed range limits.
MCA= 1,25x(FLA(FM1)+FLA(FM2)+FLA(FM3)+FLA(FM4))
MCA represents maximum input current.
MFA ≤ 4 x (FLA(FM1)+FLA(FM2)+...)
Select wire size based on the value of MCA
Fan step 8 is nominal specs.
The unit complies for "Code du travail" and "ERP 5e catégorie" applications according to French legislation.
"Code du travail" applications are non-public buildings (example offices).
"ERP (Etablissement Recevant du Public) de 5e catégorie" are smaller shops, hotels etc
Control systems Wired remote control BRC1D52 / BRC1E53A7 / BRC1E53B7 / BRC1E53C7
Simplified wired remote control for hotel
applications
BRC2E52C (heat recovery type) / BRC3E52C (heat pump type)
VAM wired remote control BRC301B61
General Supplier/
Manufacturer details
Name or trademark Daikin Europe N.V.
Product description Model identifier VAM350J7V
EB
VAM500J7V
EB
VAM650J7V
EB
VAM800J7V
EB
VAM1000J7
VEB
VAM1500J7
VEB
VAM2000J7
VEB
Type of product Bidirectional NRVU / (2)
Type of drive variable speed drive
Heat recovery system recuperative
Thermal efficiency % 77 (3) 73 (3) 74 (3) 76 (3) 73 (3) 77 (3) 73 (3)
Nominal flow rate m³/s 0.097 0.139 0.181 0.222 0.278 0.417 0.556
Effective electric power input kW 0.096 0.171 0.203 0.272 0.409 0.475 0.817
Internal specific fan power W/(m³/s) 465 (2) 663 (2) 836 (2) 757 (2) 972 (2) 721 (2) 972 (2)
Maximum external leakage % \<9 \<8
Maximum internal leakage % \<8
Filter service warning Displayed on controller / (4)
Instructions for pre-/disassembly https://www.daikin.eu/en_us/about/daikin-innovations/seasonal-efficiency.html
Face velocity m/s 0.520 0.740 0.720 0.670 0.830 0.620 0.830
External pressure Pa 90.0
Internal pressure drop Pa 106 (2) 155 (2) 196 (2) 166 (2) 216 (2) 158 (2) 216 (2)
Fan efficiency % 43.0 (5) 41.9 (5) 41.1 (5) 41.1 (5)
2-2 Electrical Specifications VAM350J VAM500J VAM650J VAM800J VAM1000J VAM1500J VAM2000J
Power supply Name VE
Phase 1~
Frequency Hz 50/60
Voltage V 220-240/220
Voltage range Min. % -10
Max. % 10
Current Minimum circuit amps (MCA) A 1.56 2.08 2.80 4.39 4.90 8.78 9.80
Maximum fuse amps (MFA) A 16.0
Fan motor rated output kW 0.08x2 0.106x2 0.210x2 0.210x4
Full load amps
(FLA)
Fan motor A 0.620 0.830 1.12 1.76 1.96 1.76 1.96
Fan motor 2 A 0.620 0.830 1.12 1.76 1.96 1.76 1.96
Fan motor 3 A - 1.76 1.96
Fan motor 4 A - 1.76 1.96
2-1 Technical Specifications VAM350J VAM500J VAM650J VAM800J VAM1000J VAM1500J VAM2000J
