SilverStone ST45NF [2/15] Nj450 manual 1

SilverStone Nightjar ST45NF

ATX12V 2.3 Switching Power Supply

With Active PFC

PS/2 450W

This specification describes the electrical characteristics, functional and physical of a

PS/2 Fanless Switching power supply; the maximum output shall be 450W when Input

Voltage is from 100V to 240V. This power supply is also design with Active PFC

(Power Factor Correction) capabilities.

2.1. AC Input Voltage, Frequency and Current (Rating: 100V-240Vac, 47-63Hz, 6-3A)

The power supply must operate within all specified limits over the input voltage

range in Table 1.

Harmonics distortion of up to 10% THD must not cause the power supply to go

out of specified limits.

Parameter Minimum Rated Maximum

Maximum

Input Current

Voltage (115V)

Voltage (230V)

Frequency

99 Vac

180 Vac

47 Hz

100-127Vac

200-240Vac

50 / 60 Hz

132 Vac

264Vac

63 Hz -

6 A

3.5 A

Table 1 - AC Input Voltage and Frequency

2.2. AC Input Current and Inrush Current

AC input current of the system shall meet the limits shown in Table 1. No damage

shall occur or overstress input fuse shall blow (as a result of inrush). Under

conditions; 132/264VAC full load turn off 1sec; turn on at peak of input voltage

cycle 25 C air ambient cold start.
