2.9. Electro Static Discharge, IEC61000-4-2

In addition to IEC61000-4-2, the following ESD tests should be conducted. Each

surface area of the unit under test should be subjected to twenty (20) successive

static discharges, at each of the follow voltages: 2KV, 3KV, 4KV, 5KV, 6KVand 8KV.

All power supply outputs shall continue to operate within the parameters of this

specification, without glitches or interruption, while the power is operating as

defined and subjected to 2kV through 10kV ESD pulses. The direct ESD event

shall not cause any out of regulation conditions such as overshoot or undershoot.

The power supply shall withstand these shocks without nuisance trips of the

Over-Voltage Protection, Over-Current Protection, or the remote +5VDC, +12VDC

shutdown circuitry.

2.10. Radiated Immunity, IEC61000-4-3

Frequency Electric Field Strength

27 MHz to 500 MHz, un-modulated 3 V/m

3.1. Output Current / Loading

The following tables define two power and current rating. The power supply shall

meet both static and dynamic voltage regulation requirements for minimum load

condition.

400W/25 C at 99Vac ~264Vac

Output Voltage

Max. Load

Min. Load

Peak Power

+3.3V +5V +12V -12V +5VSB

20A 14A 32A 0.5A 2.5A

0A 0A

0.5A

36A

0A 0A

0A 3.5A

Note 1: The +5 & +3.3 Volt total output shall not exceed 130 W.

Note 2: The +5, +3.3 & +12Volt total output shall not exceed 394W.

Note 3: Maximum continues total DC output power should not exceed 400W

Note 4: Peak Power should not exceed 450W
