• Split Sky Air • Indoor Units
9
• Indoor Units • R-410A • FTKS-FV1B
6 Sound data
6 - 1 Sound pressure spectrum
4D051229A
Octave band sound pressure level
dB:(0dB = 0.0002 μ bar)
Octave band center frequency (Hz)
FTKS50F
approximate threshold
hearing for continuous
noise
Legend
50Hz 220-240V (H)
50Hz 220-240V (L)
NOTE
1 Operation noise differs with operation and
ambient conditions.
2 Measure in anechoic room
Location of microphone
4D051232A
Octave band sound pressure level
dB:(0dB = 0.0002 μ bar)
Octave band center frequency (Hz)
FTKS60F
approximate threshold
hearing for continuous
noise
Legend
50Hz 220-240V (H)
50Hz 220-240V (L)
NOTE
1 Operation noise differs with operation and ambient
conditions.
2 Measure in anechoic room
Location of microphone
4D051230A
Octave band sound pressure level
dB:(0dB = 0.0002 μ bar)
Octave band center frequency (Hz)
FTKS71F
approximate threshold
hearing for continuous
noise
Legend
50Hz 220-240V (H)
50Hz 220-240V (L)
NOTE
1 Operation noise differs with operation and ambient
conditions.
2 Measure in anechoic room
Location of microphone
