Name of Parts
Outdoor Unit
• Appearance of the outdoor unit may differ from some models.
■
Open the front panel
Air fi lter
Titanium apatite
deodorizing fi lter
Refrigerant piping and
inter-unit wiring
Earth terminal
• It is inside of this cover.
Drain hose
Air inlet
(back and side)
Air outlet
Outdoor temperature
sensor (back)
Model name plate
