ATX 12V 4PIN (4+4PIN EPS 12V in split mode)
4PIN peripheral connector (HDD) 4PIN floppy connector (FDD)
SATA connector
Yellow
Black
Black
Red
Red
Black
Black
Yellow
Signal
+12V
COM
COM
+5VDC
Pin
1
2
3
4
Pin
1
2
3
4
Signal
+5VDC
COM
COM
+12V
8PIN PCI Express connector
Yellow
Yellow
Yellow
Black sense1
Black
Black
Black
Black
Signal
+12V
+12V
+12V
COM
Pin
1
2
3
4
Pin
5
6
7
8
Signal
COM
COM
COM
COM
6PIN PCI Express connector
Yellow
Yellow
Yellow
Black
Black
Black
Signal
+12V
+12V
+12V
Pin
1
2
3
Pin
4
5
6
Signal
COM
COM
COM
Black
Black
Yellow
Yellow
Signal
GND
GND
Pin
1
2
Pin
3
4
Signal
+12V
+12V
Orange
Black
Red
Black
Yellow
Signal
+3.3V
COM
+5V
COM
+12V
Pin
5
4
3
2
1
EPS 12V 8PIN connector
Yellow
Yellow
Yellow
Yellow
Black
Black
Black
Black
Signal
+12V
+12V
+12V
+12V
Pin
5
6
7
8
Pin
1
2
3
4
Signal
COM
COM
COM
COM
