3. OUTPUT REQUIREMENTS
ST50F-P:
3.1 OUTPUT VOLTAGE AND CURRENT
LOAD REGULATION CHARACTERISTICS
+3.3V
+5V
+12V
-12V
+5Vsb
0.5A
0.3A
0.5A
0A
0A
14.77A
12.31A
17A
0.28A
2.3A
24A
20A
34A
0.3A
2.5A
±5%
±5%
±5%
±10%
±5%
±1%
±1%
±1%
±2%
±1%
50mV P-P
50mV P-P
120mV P-P
200mV P-P
50mV P-P
MINIMUM
LOAD
MINIMUM
LOAD
MINIMUM
LOAD
LOAD
REG
LINE
REG
RIPPLE & NOISE
NO.
1
2
3
4
5
6
7
8
9
10
11
LOAD
CONDITION
OUTPUT LOAD
COND.1
COND.2
COND.3
COND.4
COND.5
COND.6
COND.7
COND.8
COND.9
COND.10
COND.11
+3.3V
X
X
0.5A
24A
6A
0.5A
12A
11A
24A
0.5A
14.77A
+5V
X
X
0.3A
0.5A
15A
4A
4A
6.8A
6A
8A
12.31A
+12V1
X
X
1A
8A
9A
19A
19A
20A
12A
34A
31.24A
-12V
X
X
0A
0.1A
0A
0A
0A
0.2A
0.3A
0.,3A
0.28A
+5Vsb
2 .5A
0A
0A
2A
2.5A
2.5A
2.5A
1.5A
0A
1A
2.3A
(1) +3.3V & +5V total output not exceed 120W.
When +5V is load to 20A, the +3.3V maximum load is 6A.
When +3.3V is load to 24A, the +5V maximum load is 8A.
(2) All outputs shall be safety-isolated from the AC mains and share a common
return. This common return must be connected to supply chassis.
(3) Voltages and ripple are measured at the load side of mating connectors with
a 0.1uF monolithic ceramic capacitor paralleled by a 10uF electrolytic capacitor
across the measuring terminals.
