SilverStone ST75F-G Инструкция по эксплуатации онлайн
October, 2010
NO.G11212840
STRIDER GOLD
ST1200-G / ST1000-G / ST85F-G / ST75F-G
The perfect balance of performance, efficiency, and quality
Содержание
- No g11212840 1
- St1200 g p131 說明書 封面封底 1
- St1200 g st1000 g st85f g st75f g 1
- Strider gold 1
- The perfect balance of performance efficiency and quality 1
- Atx12v eps 12v switching power supply with active pfc 80 plus gold ps 2 2
- Specification 2
- St1200 g p131 說明書p1 p2 2
- Strider gold series 2
- Strider gold series sst st1200 g sst st1000 g sst st85f g sst st75f g 2
- Any overshoot at turn on or turn off shall be less 10 of the norminal voltage value all outputs shall be within the regulation limit of section 2 before issuing the power good signal of section 5 3
- Maximum continuous total dc output power should not exceed 1000w 2 maximum continuous combined load on 3 vdc and 5vdc outputs shall not exceed 150w 3 maximum current for 12v outputs shall be 83a 996w 4 maximum peak total dc output power should not exceed 1100w 5 peak power and current loading shall be supported for a minimum of 12 second 6 when 12v is load to 28a 12v minimum load is 0 2a 3
- Maximum continuous total dc output power should not exceed 1200w 2 maximum continuous combined load on 3 vdc and 5vdc outputs shall not exceed 150w 3 maximum current for 12v outputs shall be 100a 1200w 4 maximum peak total dc output power should not exceed 1300w 5 peak power and current loading shall be supported for a minimum of 12 second 6 when 12v is load to 28a 12v minimum load is 0 2a 3
- Maximum continuous total dc output power should not exceed 850w 2 maximum continuous combined load on 3 vdc and 5vdc outputs shall not exceed 150w 3 maximum current for 12v outputs shall be 70a 840w 4 maximum peak total dc output power should not exceed 950w 5 peak power and current loading shall be supported for a minimum of 12 second 6 when 12v is load to 28a 12v minimum load is 0 2a 3
- Output ripple 3
- Overshoot 3
- St1200 g p131 說明書p3 p4 3
- Strider gold series 3
- Strider st1000 strider st1000 nv 3
- The ripple voltage of the outputs shall be measured at the pins of the output connector when terminated in the load impedance specified in figure 1 ripple and noise are measured at the connectors with a 0 uf ceramic capa ny condition of line voltage output load line frequency operation temperature 3
- An output short circuit is defined as any output impedance of less than 0 ohms the power supply shall shut down and latch off for shorting the 3 vdc 5 vdc or 12 vdc rails to return or any other rail shorts between main output rails and 5vsb shall not cause any damage to the power supply the power supply shall either shut down and latch off or fold back for shorting the negative rails 5vsb must be capable of being shorted indefinitely but when the short is removed the power supply shall recover automatically or by cycling ps_on the power supply shall be capable of withstanding a continuous short circuit to the output without damage or overstress to the unit 4
- Efficiency 4
- In an under voltage fault occurs the supply will latch all dc outputs into a shutdown state when 12v 5v 3 v outputs under 85 of it s maximum value 4
- No damage or hazardous condition should occur with all the dc output connectors disconnected from the load the power supply may latch into the shutdown state 4
- No load operation 4
- Over current protection 4
- Over power protection 4
- Over voltage protection 4
- Power supply efficiency typical 87 90 at normal ac main voltage and 20 100 load on all outputs 4
- Protection 4
- Remote on off control 4
- Short circuit 4
- St1000 g 4
- St1200 g 4
- St1200 g p131 說明書p5 p6 4
- St75f g 4
- St85f g 4
- Strider gold series 4
- The over voltage sense circuitry and reference shall reside in packages that are separate and distinct from the regulator control circuity and reference no single point fault shall be able to cause a sustained over voltage condition on any or all outputs the supply shall provide latch mode over voltage protection as defined in table 4
- The power supply shall have current limit to prevent the 3 v 5v and 12v outputs from exceeding the values shown in the following table if the current limits are exceeded the power supply shall shutdown and latch off 4
- The power supply will be protected against over temperature conditions caused by loss of fan cooling or excessive ambient temperature in an otp condition the psu will shutdown when the power supply temperature drops to within specifide limits the power supply shall restore power automatically the otp circuit must have built in hysteresis such that the power supply will not oscillate on and off due to temperature recovering condition 4
- The power supply will be shutdown and latch off when output power within 105 150 of rated dc output note assurance machine can work at low voltage full load won t damage machine 4
- Under voltage protection 4
- When the logic level ps on is low the dc outputs are to be enabled when the logic level is high or open collector the dc outputs are to be disabled 4
- Electromagnetic compatibility emc 5
- Environment 5
- Mechanical requirements 5
- Safety 5
- St1200 g p131 說明書p7 p8 5
- Strider gold series 5
- Timing 5
- Atx 12v 4pin 4 4pin eps 12v in split mode 6
- Connectors 6
- Eps 12v 8pin connector 6
- M b 24pin connector 6
- Pin pci express connector 6
- Sata connector 6
- St1200 g p131 說明書p9 p10 6
- Strider gold series 6
