03
Frequency Electric Field Strength
27 MHz to 500 MHz, un-modulated 3 V/m
2.10 Radiated Immunity, IEC61000-4-3
3. DC Output Specificatio
3.1 Output Current / Loading
The following tables define two power and current rating. The power supply shall meet both
static and dynamic voltage regulation requirements for minimum load condition.
Note 1: The +5 & +3.3 Volt total output shall not exceed 180 W.
Note 2: Maximum continuous total DC output power should not exceed 750 W.
Note 3: Maximum continuous load on the combined 12 V output shall not exceed 60 A
Output Voltage +5V
Max. Load 30A
Min. Load 1.0A
+3.3V
24A
1.5A
+12V1
18A
0.8A
+12V2
18A
0.8A
+12V3
18A
0.5A
+12V4
18A
0.5A
-12V
0.5A
0A
+5VSB
3A
0.1A
Table 5 - Output Loads Range 1:
Output Voltage +5V
Load Reg. +/-5%
Line Reg. ±1%
+3.3V
+/-5%
±1%
+12V1
+/-5%
±1%
+12V2
+/-5%
±1%
+12V3
+/-5%
±1%
+12V4
+/-5%
±1%
-12V
+/-10%
±1%
+5VSB
+/-5%
±1%
Ripple & Noise 50mV 50mV 120mV 120mV 120mV 120mV 120mV 50mV
Table 7 - Regulation, ripple and noise
3.2 DC Voltage Regulation, Ripple and Noise
The power supply output voltages must stay within the following voltage limits when operating at
steady state and dynamic loading conditions. All outputs are measured with reference to the return
remote sense (ReturnS) signal. The +5V,+3.3V, +12V, -12V and +5VSB outputs are measure at the
power supply connectors references to ReturnS. The +5V and +3.3V is measured at its remote sense
signal (+5VS+, +3.3VS+) located at the signal connector.
