09
4-Pin HDD / CD-ROM Drive Power Connectors
Connector housing: 4- Pin AMP: 1-480424-0 or Molex 8981-04P or Equivalent
Contact: Amp 61314-1 or Equivalent
Pin Signal Color Size
1 +12V3 Yellow/Green stripe 18 AWG
18 AWG
18 AWG
18 AWG
Black
Red
Black2 COM
3 COM
4 +5 VDC
Small 4-Pin : Floppy Disk Drive Power Connectors
Connector housing: 4- Pin AMP: 171822-4 or Equivalent
Pin Signal Color Size
1 +5 VDC Red 22 AWG
22 AWG
22 AWG
22 AWG
Black
Yellow/Green stripe
Black2 COM
3 COM
4 +12 V3
Serial ATA Power Connector
This is a required connector for systems with serial ATA devices.
Molex Housing #675820000 or Equivalent
Molex Terminal #67510000 or Equivalent
Workstation Power Connector for High Power Graphics Cards
For workstation systems with high-powered graphics cards an additional power
connector to the baseboard may be needed. This connector supplies additional +12V
power for the higher power level graphics cards used in workstation applications.
Connector housing: 6-pin Molex 45559-0002 or equivalent
Contacts: Molex 39-00-0207 or equivalent
Pin Signal Color Size
1 +12 V4 & V5
Yellow/Green stripe
18 AWG
18 AWG
18 AWG
18 AWG
RED
Black
Black
2 COM
3 +5VDC
4 COM
18 AWGOrange5 +3.3VDC
