SilverStone SST-ZM1200M [11/12] Physical characteristics size
![SilverStone SST-ZM1200M [11/12] Physical characteristics size](/views2/1722954/page11/bgb.png)
10
PCI-Express 6-Pin
PCI-Express 8-Pin
Pin Signal Color Size
1 +12 V6 Yellow/Green stripe 18 AWG
18 AWG
18 AWGYellow/Green stripe
Yellow/Green stripe2 +12 V6
3 +12 V6
Pin Signal Color Size
4 Black
18 AWG
18 AWG
18 AWGBlack
Black5
6
COM
COM
COM
Pin Signal Color Size
1
+12 V4 &
V5
+12 V4 &
V5
+12 V4 &
V5
Yellow/Green stripe 18 AWG
18 AWG
18 AWGYellow/Green stripe
Yellow/Green stripe2
3
18 AWGBlack4 COM
Pin Signal Color Size
5 Black
18 AWG
18 AWG
18 AWGBlack
Black6
7
COM
18 AWGBlack8
COM
COM
COM
9. Physical Characteristics Size
9.1 Power Supply Dimension: 150 mm(W) x 86 mm(H) x 215 mm(D)
