02
2.4 Input Current Harmonics
When the power supply is operated in 90-264Vac of Sec. 2.1, the input harmonic current drawn
on the power line shall not exceed the limits set by EN61000-3-2 class "D" standards. The power
supply shall incorporate universal power input with active power factor correction.
2.5 AC Line Dropout
An AC line dropout of 17mS or less shall not cause any tripping of control signals or protection
circuits. If the AC dropout lasts longer than 17mS the power supply should recover and meet
all turn on requirements. The power supply shall meet the regulation requirement over all rated
AC voltages, frequencies, and output loading conditions. Any dropout of the AC line shall not
cause damage to the power supply. An AC line dropout is defined as a drop in AC line to 0VAC
at any phase of the AC line for any length of time.
Attention:
1.This power supply's default setting is six +12V rail configuration
2.Turn the switch on for six +12V rails and off for single +12V rail
3.Please make sure to turn off the power supply before adjusting the switch
Note 1: Maximum continuous total DC output power should not exceed 1200 W.
Note 2: Single / Multiple rail(s) for +12V is adjustable by a switch. (Rail Merging)
3. DC Output Specification
3.1 Output Current / Loading
The following tables define two power and current rating. The power supply shall meet both static and
dynamic voltage regulation requirements for minimum load condition.
Single rail for +12V
Output Voltage +5V
Max. Load
Max. Combined
Total Output
30A
Min. Load 1.0A
180W
1180W
1140W
+3.3V
28A
0A
+12V (Single Rail)
95A
3A
-12V
0.5A
0A
+5VSB
4A
0.1A
6W 20W
Table 5 - Output Loads Range 1:
Multiple rails for +12V
Output Voltage +5V
Max. Load
Max. Combined
Total Output
30A
Min. Load 1.0A
180W
1180W
1140W/95A
+3.3V +12V1 +12V2 +12V3 +12V4 +12V5 +12V6
28A
0A
17A
0.8A
17A
0.8A
17A
0.8A
17A
0.8A
17A
0.8A
17A
0.8A
-12V
0.5A
0A
+5VSB
4A
0.1A
6W 20W
