29
ENGLISH
TIMER MODE
--------------------------------------------------------------------------------------------------------------------------
Your hi-fi system has 4 timer modes:
– The switch-on timer, which switches the hi-fi
system on at the set time and wakes you with
the input source you selected.
– The reminder timer, which switches the hi-fi
system to remind you by sounding the signal
tone at a preset time.
– The sleep timer, which switches the hi-fi sys--
tem off at a preset time.
– The recording timer, which switches on the
HiFi device at a predefined time, records the
selected program and then switches of the
device again.
Notes
7
The settings for the switch-on timer can only
be performed in standby mode.
7
The time must be set on the hi-fi system.
7
When this setting is being made, if no button
is pushed for more than 10 seconds, the hi-
fi system will end the process automatically.
You then have to start again.
Switch-on Timer
Setting the timer
1 In standby mode, press and hold »TIMER« on
the remote control.
– The Timer Mode is displayed.
2 Activate the input mode by pressing the Jog-
Shuttle.
– Display: The clock digits for the hours flash.
Note:
7
If the Switch-on timer is out of action
»TIMER OFF«, select »TIMER ON« by turning
the Jog-Shuttle and confirm by pressing on it.
3 Rotate the Jog-Shuttle to set the hour and con-
firm with »TIMER« or Jog-Shutlle.
– Display: The clock digits for the minutes flash.
4 Rotate the Jog-Shuttle to set the minutes and
confirm with »TIMER« or Jog-Shutlle.
– Display: The last selected sound source flashes.
5 Rotate the Jog-Shuttle to set the source be-
tween »FM«, »iPOD«, »CD«, »SD«, »USB« and
»BUZZER« and confirm with »TIMER« or Jog-
Shutlle.
Notes:
7
If you select »BUZZER«, » « flashes;
confirm with »TIMER« or Jog-Shutlle.
7
If you select »iPOD«, »CD«, »SD«, »USB«,
» « flashes.
7
If you select »FM« » « flashes; rotate the
Jog-Shuttle to set the desired preset station
and confirm with »TIMER« or Jog-Shutlle.
– Display: »VOL 20« (the preset volume
level) flashes.
6 Rotate the Jog-Shuttle to set the volume and
confirm with »TIMER« or Jog-Shutlle.
– Display: The current time, » « or » «; the
timer is now set and activated.
Notes:
7
If no button is pressed for 10 seconds during
the setting, the system will quit the process
automatically, and you have to start again.
7
If you select »CD«, »SD« or »USB« as the
timer source, make sure that a CD, a SD
card or an USB memory stick has been in-
serted. Otherwise the hi-fi system activates
buzzer.
7
The sound level is limited to »VOL 25«.
Activating and deactivating the
timer
1 In standby, press »TIMER« on the remote con-
trol once.
– Display shows » « or » « if the timer is
activated. They disappear when the timer is
deactivated.
Interrupting the timer
1 When the timer sounds, press
»SNOOZE « on the remote control.
– The timer signal stops.
– The timer goes off again at 5-minute intervals
(overall timer duration is 90 minutes).
Cancelling the timer for the day
1 Press »8« when the timer is sounding.
–The timer remains activated for the next day.
