8 / 20 EN
Refrigerator/User Manual
Refrigerator/User Manual
3 Installation
Refer to the nearest Authorised Service Agent
for installation of the product. To make the
product ready for use, make sure that the
electricity installation is appropriate before
calling the Authorised Service Agent. If
not, call a qualified electrician to have any
necessary arrangements carried out.
C
Preparation of the location and
electrical installation at the place
of installation is under customer's
responsibility.
B
Product must not be plugged in during
installation. Otherwise, there is the risk
of death or serious injury!
B
WARNING:Installation and electrical
connections of the product must be
carried out by the Authorised Service
Agent. Manufacturer shall not be held
liable for damages that may arise from
procedures carried out by unauthorised
persons.
A
WARNING:Prior to installation, visually
check if the product has any defects
on it. If so, do not have it installed.
Damaged products cause risks for your
safety.
C
Make sure that the power cable is not
pinched or crushed while pushing the
product into its place after installation
or cleaning procedures.
3.1 Appropriate
installation location
A
WARNING:If the door of the room
where the product will be placed is too
small for the product to pass, then the
product's doors must be removed and
the product must be turned aside to
pass it through.
• Choose a place at where you would use
the product comfortably.
• Install the product at least 30 cm away
from heat sources such as hobs, ovens,
heater cores and stoves and at least 5 cm
away from electrical ovens. Product must
not be subjected to direct sun light and
kept in humid places after installation.
• Appropriate air ventilation must be
provided around your product in order
to achieve an efficient operation. If the
product is to be placed in a recess in the
wall, pay attention to leave at least 5 cm
distance with the ceiling and side walls.
• Do not place the product on the materials
such as rugs or carpets.
• Place the product on an even floor surface
to prevent jolts.
• Your product can operate in ambinet
temperatures between -5°C to +43°C.
C
If two coolers are to be installed side
by side, there should be at least 4 cm
distance between them.
3.2 Installing the
plastic wedges
Plastic wedges are used to create the distance
for the air circulation between the product
and the rear wall. Insert the 2 plastic wedges
onto the rear ventilation cover as illustrated
in the figure. To install the wedges, remove
the screws on the product and use the screws
given in the same pouch with the wedges.
3.3 Electrical connection
Connect the product to a grounded outlet
protected by a fuse complying with the values
in the rating plate. Our company shall not be
liable for any damages that will arise when
the product is used without grounding in
accordance with the local regulations.
• Electrical connection must comply with
national regulations.
• Power cable plug must be within easy
reach after installation.
• The voltage and allowed fuse or breaker
protection are specified in the Rating Plate
which is affixed to interior of the product.
If the current value of the fuse or breaker
in the house does not comply with the
value in the rating plate, have a qualified
electrician install a suitable fuse.
• The specified voltage must be equal to
your mains voltage.
