Ubiquiti AirGrid M5 HP 27dBi [5/6] Aghp_ds_05

05

Ubiquiti Networks, Inc. Copyright © 2011, All Rights Reserved www.ubnt.com

Specifications (cont.)

AirGrid M2 HP - Operating Frequency 2412-2462 MHz

11g11n / AirMax

OUTPUT POWER: 28 dBm

DataRate Avg. TX

2.4 GHz TX POWER SPECIFICATIONS

Tolerance

1-24 Mbps -97 dBm min +/- 2 dB

MCS3 -90 dBm +/- 2 dB

MCS4 -86 dBm +/- 2 dB

MCS5 -83 dBm +/- 2 dB

MCS6 -77 dBm +/- 2 dB

MCS7 -74 dBm +/- 2 dB

AirGrid M5 HP - Operating Frequency 5470-5825 MHz*

11a11n / AirMax

OUTPUT POWER: 25 dBm

DataRate Avg. TX

5 GHz TX POWER SPECIFICATIONS

Tolerance

5 GHz RX POWER SPECIFICATIONS

MCS2 -93 dBm +/- 2 dB

MCS3 -91 dBm +/- 2 dB

MCS4 -87 dBm +/- 2 dB

MCS5 -84 dBm +/- 2 dB

MCS6 -78 dBm +/- 2 dB

MCS7 -75 dBm +/- 2 dB

TERMS OF USE

The Ubiquiti radio device must be professionally installed. Shielded ethernet cable and earth grounding must be used as conditions of product warranty. It is the installers responsibility to

follow local country regulations including operation within legal frequency channels, output power, and Dynamic Frequency Selection (DFS) requirements. For further information, please visit

www.ubnt.com.
