4
ENGLISH
•
Keep the unit in a dry cool place out of reach of
children and people with disabilities.
THIS UNIT IS INTENDED FOR HOUSEHOLD USE
ONLY. ITS COMMERCIAL USAGE AND USAGE
IN PRODUCTION AREAS AND WORK SPACES IS
PROHIBITED.
BEFORE THE FIRST USE
After the unit transportation or storage at low
temperature keep it for at least three hours at
room temperature before switching on.
FAN ASSEMBLING
•
Unpack the unit and remove any stickers that
can prevent its operation.
•
Check the unit for damages, do not use it in
case of any.
•
Screw the lower support part (18) into the base
(19) opening.
•
Insert the upper support part (17) into the lower
part (18) and turn it clockwise.
•
Place the unit on a flat surface.
•
Install the rear grid (1) on the motor unit (2)
matching the installation openings on the motor
unit (2) with the corresponding openings on the
grid (1) and fix it with the plastic nut (21) rotating
it clockwise until bumping.
•
Install the blades (20) on the motor (2) axis
matching the blades groove with the lock on
the motor axis and fix them with the plastic nut
(22). Hold the blades and screw the nut coun-
terclockwise.
•
Install the upper grid (4) on the lower grid (1)
(pic. 1).
•
Turn the upper grid clockwise until clicking, then
fasten the fixing screw (23) clockwise.
Note: There is a corresponding mark on the lower
rim for the proper front grid orientation. The open-
ing for the fixing screw on the front grid should be
at the bottom.
•
The fan is ready for operation.
USAGE
Before using the unit for the first time, make sure
that the mains voltage corresponds to the unit oper-
ating voltage.
•
Insert the power plug into the socket, you will
hear a sound signal. The unit is connected to
the mains.
•
Press the “ON/OFF” power button (15).
Note:
– the control panel buttons are duplicated by the
control panel buttons;
– every pressing of the control buttons (11, 12, 13,
14) is accompanied with a sound signal;
– when switched on for the first time, the fan starts
operating at the medium air flow speed (Me) by
default, then switching to the low air flow speed (Lo).
The fan operating mode starts as normal (NOR).
•
Repeatedly press the “SPEED” button (14) to
select the blades rotation speed. The light indi-
cators (10) show the selected blades rotation
speed:
– “Lо” – low air flow speed;
– “Me” – medium air flow speed;
– “Hi” – high air flow speed.
•
Press the “SWING” button (11) to switch the fan
60° rotation operation mode on, the “SWING”
rotation mode indicator (7) will light up.
•
To stop the rotation mode, press the “SWING” but-
ton (11) again, the “SWING” indicator (7) will go out.
•
Automatic switch-off timer operation time is
selected by the “TIMER” button (12), the light
indicators (8) will inform about the set time.
You can set the fan operation time from 0.5 to
7.5 hours (with an 0.5 hour setting increment).
•
To switch the timer off press the “TIMER” button
(11) repeatedly until all the indicators (7) go out.
•
Select the air flow mode with the “MODE” but-
ton, the light indicators show the selected mode:
– “NOR” – just ventilation;
– “NAT” – natural wind;
– “SLEEP” – dropping wind.
•
To switch the fan off press the “ON/OFF” but-
ton (14).
•
You may change and fix the position of the fan
motor unit (2) in accordance with the required air
flow vertical angle, the fan slope angle is set manu-
ally. Clicking while the fan is being tilted is normal.
Installing batteries in the remote control (RC)
•
Open the RC battery compartment lid and insert
a CR2025 battery, strictly following the polarity.
•
Install the battery compartment lid back to its
place.
Note: The unit can be supplied with the battery
installed in the RC battery compartment. In this
case if there is an isolation insert in the RC battery
compartment, remove the insert.
Battery replacement
•
Open the battery compartment lid, replace the
old battery with a new one, strictly following the
polarity, then close the battery compartment lid.
MAINTENANCE AND CARE
•
Before cleaning the fan switch it off by pressing
the “ON/OFF” button (15) on the control panel
(7) or on the remote control (16) and unplug it.
•
Do not use abrasive cleaners and solvents to
clean the unit.
