94
11 MENU SCREEN OPERATION
DD
GPS mode
Sets GPS mode operation ON and OFF.
When the position information is received from a connected
GPS receiver and the GPS Auto TX Timer setting (p. 95) is
set to a specific time, the transceiver automatically transmits
with the current position and message at every setting inter-
val.
(default: OFF)
• Sentence formatter setting
q Select “ON” in GPS mode item, then push [ï](5)
†
to enter
the sentence formatter selection.
w Rotate [DIAL]
†
to select the desired sentence formatter.
• RMC, GGA, GLL, GSA and VTG are selectable.
e Push [ï](5)
†
to enter the desired sentence formatter se-
lection.
r Rotate [DIAL]
†
to select the setting.
t Rotate [DIAL]
†
to select next sentence and repeat steps
w to r, or push [MENU/LOCK] to return to frequency in-
dication.
• Only three sentence formatters can be activated at same time.
OFFOFF
ONON
RMC SENTENCE
r
OFFOFF
ONON
RMC SENTENCE
r
RMC:OFFRMC:OFF
GGA:ONGGA:ON
GLL:OFFGLL:OFF
GSA:OFFGSA:OFF
VTG:OFFVTG:OFF
GPS SENTENCE
r
RMC:OFFRMC:OFF
GGA:ONGGA:ON
GLL:OFFGLL:OFF
GSA:OFFGSA:OFF
VTG:OFFVTG:OFF
GPS SENTENCE
r
OFFOFF
ONON
:SENTENCE
GPS MODE
r
:SENTENCE
OFFOFF
ONON
GPS MODE
r
†
[DIAL] ↔ [
∫∫
](2)/[
√√
](8) [ï](5) ↔ [
≈≈
](6)
