SET MODES

D VOX delay

Sets the VOX Delay to between “VXd.05” (0.5 sec.), “VXd.10”

(1 sec.), “VXd.15” (1.5 sec.), “VXd.20” (2 sec.), “VXd.25” (2.5

sec.) and “VXd.30” (3 sec.).

The VOX Delay is the amount of time the transmitter stays

ON after you stop speaking. (default: VXd.10)

D VOX time-out timer

Sets the VOX time-out timer to between 1, 2, 3, 4, 5, 10 and

15 min. to prevent accidental prolonged transmission for the

VOX function.

To turn the function OFF, select “Vto.OF.” (default: Vto.03)

The VOX time-out timer must be set shorter than the time-

out timer, otherwise this timer will not be activated.

D DTMF TX key

Selects the method to transmit a DTMF code sequence.

While pushing and holding [PTT], push one of the keys,

[0] to [9], [MONI](A), [](B), [](C), [VFO/MR/CALL](D),

[

]

(E),and

[

# ENT

]

(F).

• dmt.k : Transmits the appropriate DTMF code assigned to the

key. (default)

• dmt.m :

Transmits the programmed DTMF code sequence in

the DTMF memory channel assigned to the key.

• dmt.t : No DTMF code can be transmitted. However, while

pushing and holding [PTT], push either the [] or []

to transmit a 1750 Hz tone burst signal.

D Operating mode

Set the operating mode to FM or FM-N. The operating mode

is determined by the modulation of the radio signals.

(default: W/n. W)

FM mode

FM-N mode
