Icom IC-V80 [58/64] Options
![Icom IC-V80 [58/64] Options](/views2/1074095/page58/bg3a.png)
51
OPTIONS
14
• BP-263 battery case
Battery case for LR6 (AA) × 6 alkaline batteries.
• BP-264 ni-mh battery pack
7.2 V/1400 mAh (Typ.) Ni-MH battery pack. Battery life: 13 hrs.
(approx.; FM, high power, Tx : Rx : Standby = 5:5:90)
• BP-265 li-ion battery pack
7.4 V/1900 mAh (Min.)/2000 mAh (Typ.) Lithium Ion battery
pack. Battery life: 19 hrs. (approx.; FM, high power, Tx : Rx :
Standby = 5:5:90)
• BC-191 desktop charger+BC-123S ac adapter
For rapid charging of the Ni-MH battery pack. An AC adapter
may be supplied with the charger, depending on the version.
Charging time: approx. 2 hours for the BP-264.
• BC-192 desktop charger+BC-147S ac adapter
For regular charging of the Ni-MH battery pack. An AC adapter
may be supplied with the charger, depending on the version.
Charging time: approx. 16 hours for the BP-264.
• BC-193 desktop charger+BC-123S ac adapter
For rapid charging of the Li-Ion battery pack. An AC adapter
may be supplied with the charger, depending on the version.
Charging time: approx. 2.5 hours for the BP-265.
• CP-23L cigarette lighter cable
Allows charging of the battery packs through a 12 V cigarette
lighter socket. (For only BC-191/BC-193)
• OPC-515L dc power cable
Allows charging of the battery packs using a 12 V DC power
source instead of the AC adapter. (For all chargers)
• MB-124 belt clip
Exclusive alligator-type belt clip.
• FA-B2E vhf antenna
The same antenna that is supplied with the transceiver.
• HM-153L earphone-mirophone
Ideal for hands-free operation: clip the HM-153L (with inte-
grated PTT switch) to your lapel or breast pocket.
• HM-158L/HM-159L speaker-mirophone
Combination speaker-microphone that provides convenient
operation while hanging the transceiver on your belt.
•
HS-94/HS-95/HS-97 headset+OPC-2004 plug adapter cable
HS-94 : Ear hook type
HS-95 : Neck & arm type
HS-97 : Throat microphone
OPC-2004 : Allows you to connect the HS-94/HS-95/HS-97 to
the transceiver. After connecting, the VOX function
can be used.
• SP-27 tube earphone
Provides clear audio in noisy environments.
•
CS-V80
cloning software+
OPC-478
/
OPC-478UC
cloning cable
Provides quick and easy programming of such settings as
memory channels and Set modes contents.
• OPC-474 cloning cable
For transceiver-to-transceiver cloning.
Some options may not be available in some countries. Please
ask your dealer for details.
