Icom IC-F3011 [29/48] D ad 106 installation
![Icom IC-F4011 [29/48] D ad 106 installation](/views2/1074164/page29/bg1d.png)
23
5
BATTERY CHARGING
D AD-106 installation
The AD-106 charger adapter must be installed into the BC-119N
or BC-121N before battery charging.
➥Connect the AD-106
charger adapter and the BC-119N/BC-
121N as below, then install the AD-106 into the holder space of
the BC-119N or BC-121N with the supplied screws.
Desktop charger
adapter
Connectors
Plugs
Screws supplied
with the charger
adapter
This illustration is described with the BC-119N.
