Icom IC-F3011 [38/48] Options
![Icom IC-F3011 [38/48] Options](/views2/1074164/page38/bg26.png)
32
8
OPTIONS
D BATTERY PACK
Battery pack Voltage Capacity Battery life*
1
BP-230N 7.4 V
950 mAh (min.)
980 mAh (typ.)
9 hrs.
BP-232N 7.4 V
1900 mAh (min.)
2000 mAh (typ.)
18 hrs.
BP-240
Battery case for AAA
(LR03) × 6 alkaline
—*
2
*
1
When the power save function is turned ON, and the operating pe-
riods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
*
2
Operating period depends on the alkaline cells used.
D CHARGERS
• BC-119N desktop charger + AD-106 charger adapter
+ BC-145S
ac adapter
For rapid charging of battery packs. An AC adapter is supplied
with the charger depending on versions.
Charging time:
approx. 3 hours when BP-232N is attached.
• BC-121N
multi-charger + AD-106 charger adapter (6 pcs.)
+ BC-157
ac adapter
For rapid charging of up to 6 battery packs (six AD-106’s are required)
simultaneously. An AC adapter should be purchased separately.
Charging time: approx. 3 hours when BP-232N is attached.
• BC-160
desktop charger + BC-145S ac adapter
For rapid charging of battery packs. An AC adapter is supplied
with the charger depending on versions.
Charging time:
approx. 3 hours when BP-232N is attached.
