Icom IC-F3011 [39/48] D antennas
![Icom IC-F3011 [39/48] D antennas](/views2/1074164/page39/bg27.png)
33
8
OPTIONS
• BC-171 desktop charger + BC-147S ac adapter
For regular charging of battery packs. We recommend that the
BP-230N charging. An AC adapter is supplied with the charger
depending on versions.
Charging time:
Approx. 10 hours when BP-232N is attached.
Approx. 4 hours when BP-230N is attached.
D BELT CLIPS
• MB-93 swivel belt clip
• MB-94 belt clip
Exclusive alligator-type belt clip.
• MB-96N/96F
leather belt hanger
D DC CABLES
• CP-17L cigarette lighter cable
Allows charging of the battery pack through a 12 V cigarette lighter
socket. (For BC-119N)
• OPC-515L/OPC-656
dc power cables
Allows charging of the battery pack using a 13.8 V power source
instead of the AC adapter.
OPC-515L:
For BC-119N
OPC-656 : For BC-121N
D ANTENNAS
• FA-SC73US/FA-SC56VS/FA-SC57VS stubby antennas
FA-SC73US: 450–490 MHz FA-SC56VS: 150–162 MHz
FA-SC57VS: 160–174 MHz
• FA-SC01U/FA-SC25U/FA-SC57U/FA-SC72U/FA-SC25V/
FA-SC55V
antennas
FA-SC01U: 350–400 MHz FA-SC25U: 400–430 MHz
FA-SC57U: 430–470 MHz FA-SC72U: 470–520 MHz
FA-SC25V: 136–155 MHz FA-SC55V: 146–174 MHz
• FA-SC61VC/FA-SC61UC
cut antennas
FA-SC61VC: 136–174 MHz FA-SC61UC: 380–520 MHz
