• BC-197 m u l t i -c h a r g e r
For rapid
simultaneously
charging of up to six battery packs
.
An
AC adapter may
be supplied with the charger, depending on the
version.
There are two types of BC-197 chargers for the IC-F3000/
IC-F4000 series.
BC-197 Charger Type Chargeable Battery Charging time
With AD-120* BP-264 Ni-MH battery Approx. 2 hrs.
With AD-121* BP-265 Li-ion battery Approx. 2.5 hrs.
* Either AD-120 or AD-121 charger adapters are installed in the BC-
197, depending on the chargeable battery pack.
D DC POWER CABLES
• CP-23L c i g a r e t t e l i g h t e r c a b l e
Allows charging of the battery pack through a 12 V cigarette lighter
socket. (For BC-191/BC-193)
• OPC-515L
d c p o w e r c a b l e
Allows charging of the battery pack using a power source instead
of the AC adapter.
D BELT CLIPS
• MB-124 b e l t c l i p
Exclusive alligator-type belt clip.
D ANTENNAS
• FA-SC73US/FA-SC56VS/FA-SC57VS s t u b b y a n t e n n a s
FA-SC73US : 450–490 MHz FA-SC56VS : 150–162 MHz
FA-SC57VS : 160–174 MHz
• FA-SC25U/FA-SC57U/FA-SC72U/
FA-SC25V/FA-SC55V
a n t e n n a s
FA-SC25U : 400–430 MHz FA-SC57U : 430–470 MHz
FA-SC72U : 470–520 MHz FA-SC25V : 136–155 MHz
FA-SC55V : 146–174 MHz
• FA-SC61VC/FA-SC61UC
c u t a n t e n n a s
FA-SC61VC : 136–174 MHz FA-SC61UC : 380–520 MHz
