■ Supplied accessories
The following accessories are supplied with the transceiver.
Flexible antenna
(This illustration is for the VHF type.)
Battery pack*
Belt clip*
Jack cover
(with screws)
Battery charger*AC adapter*
* Not supplied, or the shape is different, depending on the version.
■ Accessory attachments
D Flexible antenna
Connect the flexible antenna to the antenna connector.
CAUTION:
• NEVER
carry the transceiver by hold-
ing only the antenna.
• DO NOT connect the antenna other
than listed on page 36.
• Transmitting without an antenna will
damage the transceiver.
1
1
ACCESSORIES
