8
2
PANEL DESCRIPTION
MEMORY CH 1/2/3/4 KEYS “CH1” “CH2” “CH3” “CH4”
Push to directly select memory channels 1 to 4.
MONI KEY “MON”
➥ Push to mute and release the CTCSS (DTCS) or 2-tone
squelch mute. Open any squelch or deactivate any mute
while holding down this key. (LMR operation only)
➥ Independently activates one or two of the following func-
tions on each channel. (PMR operation only)
• Hold down to unmute the channel (audio is heard; ‘Audible’
mode).
• Push to mute the channel (sets to ‘Inaudible’ only).
• Push after the communication is nished to send a ‘reset code’.
(5-tone/BIIS operation only)
NOTE: The unmute mode (‘Audible’ mode) may auto-
matically return to the mute mode (‘Inaudible‘ mode)
after a specified period.
LIGHT KEY “LIGT”
Push to temporarily turn ON the transceiver’s backlight, only
when the backlight function is turned OFF in the User set mode.
LOCK KEY “LOCK”
➥ Hold down for 1 second to electronically lock all program-
mable keys to prevent accidental frequency changes and
unnecessary function access, except the following:
[PTT], [Call] (incl. Call A and Call B), [Moni(Audi)],
[Light], [Emergency], [Surveillance], [Lone Worker] and
[OPT 1/2/3].
➥
Hold down for 1 second again to turn the lock function OFF.
LONE WORKER KEY “LONE”
Push to turn the Lone Worker function ON or OFF.
• If the Lone Worker function is activated, the Emergency function is
automatically turned ON after the specified time period has passed
with no operation performed.
HIGH/LOW KEY “H/L”
Push to select the transmit output power temporarily or per-
manently, depending on the presetting.
• Ask your dealer for the output power level for each selection.
TONE/RAN CH SELECT KEY “T SEL”
➥ While in the analog mode, push to enter the continuous
tone channel selection mode. Then select the desired tone
frequency/code setting using [CH Up] or [CH Down]. After
the selection, push this key again to set the tone/code.
➥ While in the digital mode, push to enter the RAN channel
selection mode. Then select the desired RAN setting using
[CH Up] or [CH Down]. After the selection, push this key
again to set the RAN.
➥ While in the mixed (digital and analog) mode, push to enter
the continuous tone channel selection mode. Then select
the desired tone frequency/code setting using [CH Up] or
[CH Down]. After the selection, push this key to set the
tone/code. After that, the RAN channel selection screen
appears. Select the desired RAN setting using [CH Up] or
[CH Down]. After the selection, push this key again to set
the RAN.
