ACCESSORIES

Battery pack D

To attach the battery pack:

Slide the battery pack in the direction of the arrow (q) until the

battery release button makes a ‘click’ sound.

NOTE: Push on the bottom of the pack to make sure the

release button is ﬁrmly locked.

To remove the battery pack:

Push the battery release button in the direction of the arrow

(w), as shown below. The battery pack is then removed.

NEVER remove or attach the battery pack when the trans-

ceiver is wet or soiled. This may result water or dust get-

ting into the transceiver/battery pack and may result in the

transceiver being damaged.

Battery release

button

Battery pack

NOTE: Keep the battery pack terminals clean. It’s a good

idea to occasionally clean them.

Belt clip D

To attach the belt clip:

q Remove the battery pack if it is attached.

w Slide the belt clip in the direction of the arrow until the belt

clip locks and makes a ‘click’ sound.

To detach the belt clip:

q Remove the battery pack if it is attached.

w Pinch the clip (q), and slide the belt clip in the direction of

the arrow (w).
