Icom IC-F1821 [17/36] Basic operation

BASIC OPERATION

D Individual ID code selection

(Digital mode operation only)

If the transceiver has [Individual] assigned to it, the indication

can be toggled between the operating channel number (or

name) and Individual ID code (or name). When the Individual

ID code (or name) is displayed, [CH Up], [CH Down] or [CH

Up/Down] selects the desired Individual ID code.

q Push [Individual]— an Individual ID code (or name)

appears.

w Push [CH Up] or [CH Down], or rotate [CH Up/Down] to

select the desired Individual ID code.

e Push [PTT] to transmit the selected Individual ID code.

r Push [Individual]— cancels the selected Individual ID code

(return to the pre-set Talkgroup ID code in the channel.)

D Talkgroup ID code selection

(Digital mode operation only)

If the transceiver has [Talkgroup] assigned to it, the indication

can be toggled between the operating channel number (or

name) and Talkgroup ID code (or name). When the Talkgroup

ID code (or name) is displayed, [CH Up], [CH Down] or [CH

Up/Down] selects the desired Talkgroup ID code.

q Push [Talkgroup]— a Talkgroup ID code (or name)

appears.

w Push [CH Up] or [CH Down], or rotate [CH Up/Down] to

select the desired Talkgroup ID code.

e Push [PTT] to transmit the selected Talkgroup ID code.

r Change the channel— cancels the selected Talkgroup ID

code (return to the pre-set Talkgroup ID code in the chan-

nel.)

D DTMF transmission

If the transceiver has [DTMF Autodial] assigned to it, the auto-

matic DTMF transmission function is available. Up to 8 DTMF

channels are available.

TO SELECT A TX CODE:

q Push [DTMF Autodial]— a DTMF channel appears.

w Push [CH Up] or [CH Down], or rotate [CH Up/Down] to

select the desired DTMF channel.

e Push [DTMF Autodial] to transmit the DTMF code in the

selected DTMF channel.
