27
4
CONNECTION AND MAINTENANCE
4
■ Supplied Accessories
• Function name stickers
There are no names on the programmable function keys
since the functions can be freely assigned to these keys.
Attach the supplied function name stickers as below to the
appropriate keys for easy recognition of that key’s assigned
function.
Then, protect the attached stickers from unsticking with the
supplied key cap as below.
Function name sticker
Key cap
KEY-STICKER
Microphone
Microphone hanger
and screw set
Microphone
hanger cable
DC power cable
Mounting bracket
Speaker*
Key cap
Function name
stickers
Flat washers
Spring washers
Bracket bolts
Mounting screws
(M5×12)
Self-tapping screws
(M5×16)
Nuts
*Depending on version
