Icom IC-F9511HT [15/32] Wake up function
![Icom IC-F9511HT [15/32] Wake up function](/views2/1074237/page15/bgf.png)
10
2
BASIC OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
t Push [Clock] to set.
• The next item blinks.
1 2 H R 0 3 :00PM
Y M D 0 8 - 0 4 - 0 1
y Repeat steps e to t to set items.
u After setting, push and hold [Clock] for 1 sec. to program.
• Return to the time and date setting mode.
i Push [Clock] to return to the stand-by mode.
n Wake up function
The wake up function allows the transceiver to be automati-
cally turned ON according to the wake up time setting.
q Push and hold [Clock] for 1 sec. to enter the clock set
mode.
• “WAKE UP” is indicated.
W A K E U P
O F F
w Push [CH Up] or [CH Down] to turn the wake up function
ON.
e Push [Clock] to set, and select “WAKE UP TIME.”
W A K E U P T I M E
0 7 : 2 5 A M
r Push [CH Up] or [CH Down] to enter the wake up time edit
mode.
• The ‘hour’ digit blinks.
W A K E U P T I M E
0 7 : 2 5 A M
☞ Continues to the next page
