Icom IC-FR9020 [11/20] Dtmf encode
![Icom IC-FR9020 [11/20] Dtmf encode](/views2/1074249/page11/bgb.png)
6
11 KEY-LOCK
Push [SHIFT] + [8] to enable and disable the key-lock.
This symbol shows on the LCD. Key-lock and Key-
Unlock icon is displayed for 2 seconds and then reverts
to show the TGID. The [PTT], [MON] and [SHIFT] key
are not locked. If [PTT], [MON] and [SHIFT] needs to
be locked, select DISABLE in the programming soft-
ware. If the station is to be remotely controlled it is rec-
ommended to leave [PTT] enabled, remote [PTT] will
not work when [PTT] is locked. To release key lock,
push [SHIFT] + [8] again.
Figure 24 shows Key locked.
Figure 25 shows Key unlocked.
Figure 24
Figure 25
12 MANUAL CWID START AND
STOP
Push [SHIFT] + [A] to manually send the programmed
CWID.
CAUTION: The transmitter will energize immediately
when [A] is pushed.
To turn off CWID, push [SHIFT] + hold [B] for 2 sec-
onds. (This disables both programmed and manual
CWID.)
To return to normal operation, either reboot the radio
or push [SHIFT] + hold [B] for 2 seconds. (CWID must
be enabled in programming to use these functions.)
Figure 26 shows CWID Sending.
Figure 27 shows CWID function stop.
Figure 28 shows CWID function start.
Figure 26
Figure 27
Figure 28
13 DTMF ENCODE
Push [SHIFT] + [#] and then enter 0-9, [Q] or [#] to
transmit DTMF. The DTMF modulation level will be the
same as the CWID level.
Figure 29 displays DTMF Encode mode.
Figure 29
14 ANALOG CHANNEL DATA
Push [SHIFT] + [7] to scroll through the data. [7] must
be depressed to scroll.
1) RX width (narrow/wide/4 kHz)
2) TX width (narrow/wide/4 kHz)
3) Base mode (Simplex/Semi-duplex/Duplex/Repeat-
er)
4) RX CTCSS/DCS, CTCSS and DCS are used in RX
5) TX CTCSS/DCS, CTCSS and DCS are used in TX
6) TX RX Modulation type either PM or FM (PM is the
default)
(Depending on the pre-setting, this information cannot
be displayed. Ask your dealer for details.)
Figure 30 displays indicates a narrow channel during
scroll.
Figure 30
RX
TX
C001 TAC 2 MD N
Key-Unlock
CWID sending
Code: ICOM
C001 TAC 2 MD N
DTMF Encode
123456
MD N
RX
TX
C001 TAC 2 MD N
RX Narrow Channel
RX
TX
C001 TAC 2 MD N
Key-Lock
RX
TX
C001 TAC 2 MD N
CWID function stop
RX
TX
C001 TAC 2 MD N
CWID function start
