7
15 P25 CHANNEL DATA
Push [SHIFT] + [Q] to scroll through the data, [Q] must
be depressed to scroll.
1. Unit ID (source address)
2. RX NAC
3. TX-NAC
4. TGID
5. Emergency Alarm RCV
6. Call Alert RCV
7. Radio Check RCV
These functions may be enabled and disabled in the
programming software’s “MISCELLANEOUS/INFOR-
MATION DISPLAY” section.
Figure 31 shows the Unit ID.
Figure 31
16 BAR GRAPH/CHANNEL DIS-
PLAY
Push [SHIFT] + [CH] to eliminate the channel name/
bar graph and display the frequencies for TX and RX.
Push [SHIFT] + [CH] to toggle back.
Figure 32 displays the frequencies instead of channel
name.
The 1st and 2nd character on line 1 indicates Receive
Channel.
The 3rd character indicates Wide band.
The 4th character indicates Simplex mode.
The modes of operation are: “S” = Simplex, “H” = Semi
duplex; “D” = Duplex and “R” = Repeat Line 2, “TXN”
indicates TX is Narrow band.
Figure 32
17 LCD BACKLIGHT TOGGLE
By Default, the Backlight illuminates for 5 seconds af-
ter pushed any key then goes out. Push [SHIFT] + [1]
for the backlight to stay ON. Push [SHIFT] + [1] again
to return to default operation.
Figure 33 Indicates the Backlight is ON.
See section 4 for backlight timer settings.
Figure 33
18 CHANGING TX POWER
Push [SHIFT] + [2] to select High or Low TX power.
When high power is selected, the icon “ ” appears. If
the radio is programmed for high power, the radio can
be changed to low power with this function. If the radio
is programmed for low power, it can be switched to
high power with this function.
Figure 34 displays the high power symbol.
Figure 34
19 CALLER ID
In Simplex mode the IC-FR9010/FR9020 display indi-
cates the source Unit ID or Individual ID.
Figure 35 displays the Source ID as 00000366 in group
call mode.
Figure 36 displays the Source ID in Individual call
mode.
Figure 35
Figure 36
RXWS 154.600
TXN 154.600
C001 TAC 2 MD N
GPC 00001
RX
TX
C001 TAC 2 MD N
Light turn ON
RX
TX
C001 TAC 2 MD N
GPC 00001
RX
TX
C001 TAC 2 MD N
CAL 00000366 (GPC)
RX
TX
C001 TAC 2 MD N
CAL 00000366 (IDC)
8. Radio Inhibit RCV
9. Radio Uninhibit RCV
10. Status Update RCV
11. Status Request RCV
12. Short Message RCV
13. Radio Monitor RCV
RX
TX
C001 TAC 2 MD N
Unit ID 00000047
