SUPPLIED ACCESSORIES AND ATTACHMENTS
2
■ Supplied accessories
The following accessories are supplied: Qty.
• Handstrap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
• Belt clip (MB-103) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
• Ni-Cd battery pack (BP-225) . . . . . . . . . . . . . . . . . . . . . . 1
• Battery charger (BC-158) . . . . . . . . . . . . . . . . . . . . . . . . . 1
• Screws for the BC-158 (M3.5 × 20) . . . . . . . . . . . . . . . . . 2
• AC adapter (BC-147A) . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
• Flexible antenna (FA-S59V) . . . . . . . . . . . . . . . . . . . . . . . 1
■ Attachments
D Flexible antenna
Connect the supplied flexible an-
tenna to the antenna connector.
CAUTION: Transmitting without
an antenna may damage the
transceiver.
NEVER HOLD by the antenna
when carrying the transceiver.
D Handstrap
Pass the handstrap through the
loop on the top of the transceiver
as illustrated at right. Facilitates
carrying.
D Belt clip
Attach the belt clip to the transceiver as illustrated below.
Supplied screws
M
IC
/S
P
