Icom BC-146 [2/2] Spacer combinations
![Icom BC-146 [2/2] Spacer combinations](/views2/1074365/page2/bg2.png)
•Charging with the IC-F11 Series
Attach the spacer (SpacerB/C) to the adapter
(SpacerA) with the orientation as illustrated in the
diagram above.
•Attach the spacer (Spacer B/C) to the adapter with
the orientation of the stamp “ ” pointing up.
•Charging with the IC-F3G Series
Attach the spacer (SpacerB/C) to the adapter
(SpacerA) with the orientation as illustrated in the
diagram above.
•Attach the spacer (SpacerB/C) to the adapter with
the orientation of the stamp “ ” pointing up.
When removing the spacer (SpacerB/C)
Push the notch carefully with your finger to remove
the spacer (SpacerB/C) from the adapter (SpacerA).
R CAUTION!
DO NOT push or force the notch with a screw
driver, etc., to remove it.
DO NOT bend the notch when the adapter and
spacer are not joined together. This will cause
weakening of the notch plastic.
Both cases may break the notch and it may not
be able to be reattached.
•Charging with the IC-F30G Series
The adapter (Spacer A) only is required.
Spacer A
Check orientation
and
Spacer A
Spacer B/C
Check orientation
and
Spacer A
Spacer B/C
Push the notch
carefully.
Remove the spacer (Spacer B/C)
from the adapter.
SPACER COMBINATIONS
, Icom Inc. are registered trademarks of Icom Incorporated (Japan) in the United States and/or other countries.
