Icom IC-F4GT [15/16] Option
![Icom IC-F4GT [15/16] Option](/views2/1074491/page15/bgf.png)
25
9
CLONING
26
10
OPTION
‘‘
Options
DD
BATTERY PACKS
• BP-208
BATTERY CASE
Allows a set of Alkaline batteries to operate the handheld when
charging the rechargeable battery or in emergencies, etc. 6 AA
(R6) cells are required.
• BP-209
N
i
-
C
d
BATTERY PACK
7.2 V/1100 mAh Ni-Cd battery pack, allows more than 8 hours op-
eration.
• BP-210
N
i
-
HM BATTERY PACK
7.2 V/1650 mAh Ni-MH battery pack, allows approx. 11 hours op-
eration.
DD
CHARGER
• BC-144
DESKTOP CHARGER
+ BC-145
AC ADAPTOR
For rapid charging of battery packs. An AC adapter is supplied
with the charger. Charging time: 1.5 to 2 hrs.
• BC-137 (#11)
BATTERY CHARGER
+ BC-122
AC ADAPTOR
For regular charging of battery packs. An AC adapter is addition-
ally required. Charging time: 15 hrs.
• BC-146
BATTERY CHARGER
+ BC-147
AC ADAPTOR
For regular charging of battery packs. An AC adapter is addition-
ally required. Charging time: 18.5 hrs.
• BC-121
MULTI
-
CHARGER
+ AD-94 (#11)
CHARGER ADAPTOR
(6 pcs.)
For rapid charging of up to 6 battery packs (six AD-94’s are re-
quired) simultaneously. An AC adapter may be supplied depend-
ing on version. Charging time: 1.5 to 2 hrs.
• BC-119
DESKTOP CHARGER
+ AD-94 (#11)
CHARGER ADAPTOR
For rapid charging of battery packs. An AC adapter is supplied
with the charger. Charging time: 1.5 to 2 hrs.
DD
PC-to-transceiver cloning
Please refer to the HELP file that comes with the CS-F3G
CLONING SOFTWARE.
CAUTION: Imprudent cloning operation causes a cloning error.
In such a case, memory contents may be lost. Cloning must
then be repeated.
