PANEL DESCRIPTION
¡¡
SCAN START/STOP KEY
Push this key to start scanning; and push again
to stop.
NOTE: Place the microphone on hook to start
scanning.
Take the microphone off hook to stop scanning.
¡¡
SCAN TAG KEY
Adds or deletes the selected channel to the scan
group.
¡¡
PRIORITY CHANNEL KEYS
Push these keys to select priority A or priority B
channel, respectively.
¡¡
OPERATING CHANNEL KEYS
Select an operating channel directly.
PRI A
PRI B
CH1
CH2
CH3
CH4
TAG
¡¡
MONITOR KEY
Activates one of (or two of) the following functions
on each channel independently:
• Push and hold the key to unmute the channel (audio
is emitted; ‘Audible’ condition).
• Push the key to toggle between the mute and unmute
conditions (toggles between ‘Audible’ and ‘Inaudible’).
• Push the key to mute the channel (sets to ‘Inaudible’
only).
• Push the key to unmute the channel (sets to ‘Audible’
only).
• Push the key after communication is finished to send a
‘reset code’.
NOTE: The unmute condition (‘Audible’ condi-
tion) may automatically return to the mute con-
dition (‘Inaudible’ condition) after a specified
period depending on the pre-setting.
¡¡
LOCK KEY
Push this key for 1 sec. to lock all programmable
keys except the following:
• [
CALL
] (incl. [CAL A] and [CAL B]), [
MONI
] and
[
EMER
] keys.
MONI
SCAN A
SCAN B
LOCK
