Icom IC-F121 [8/24] Panel description
![Icom IC-F121 [8/24] Panel description](/views2/1074515/page8/bg8.png)
5
1
PANEL DESCRIPTION
¡¡
OUTPUT POWER SELECTION KEYS
Select the transmit output power temporarily, or
permanently, depending on the pre-setting.
• Contact your dealer for the output power level for each
selection.
¡¡
TALK AROUND KEY
Turns the talk around function ON and OFF.
• The talk around function equalizes the transmit fre-
quency to the receive frequency for mobile-to-mobile
communication.
¡¡
WIDE/NARROW KEY
Push this key to toggle the bandwidth between
wide or narrow.
¡¡
DTMF AUTODIAL KEY
Push this key to display the text of the DTMF
channel number and set the desired channel
number via the []/[]key. Then, push this
key again to transmit a specified DTMF code.
TA
W/N
¡¡
CALL KEY
Transmit a 2-tone, 5-tone code.
• Call transmission is necessary before you call another
station depending on your signaling system.
• The [CAL A] and/or [CAL B] keys may be available
when your system employs selective ‘Individual/Group’
calls. Contact your dealer about which call is assigned
to each key.
¡¡
EMERGENCY KEY
Push and hold the key to transmit an emergency call.
• If you want to cancel the emergency call, push and
hold (or push) the key again before transmitting the
call.
• Depending on the pre-setting, the emergency call is
transmitted one time only, or repeatedly, until receiving
a control code.
¡¡
HOOK SCAN
When the Hook Scan function is turned ON, push
this key to stop scanning temporarily. Push this
key again to re-start scanning.
¡¡
TX CODE KEY
Select a transmit 5-tone code (station code) chan-
nel.
EMER
HOOK
H/L
CALL
CAL A
CAL B
DTMF
TX CH
IC-F111_F121_F211_F221.qxd 02.12.26 10:09 AM Page 5 (1,1)
